EASYBURN Napkin burning machine efficiently reduces waste volume and promotes eco-friendly disposal by incinerating used napkins.
USAGE |
50 NAPKINS PER CYCLE |
---|---|
MODE |
FULL AUTOMATIC |
FULL AUTOMATIC |
290B x 305H x 530L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless steel SS304
Loading Door : Freely operating hinged Front-loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/5 00C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Air tight front loading inlet door
Loading capacity : 50 Napkins per cycle, 300 Napkins per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less in such cases there is a probability of complaints due to over heating or over loading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
30 NAPKINS PER CYCLE |
---|---|
MODE |
FULL AUTOMATIC |
FULL AUTOMATIC |
290B x 305H x 530L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front-loading door, ceramic insulated airtight metal door, prevent heat loss
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 6-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 180 Napkins per day, 6 Cycles per day.
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less in such cases there is a probability of complaints due to over heating or over loading of machine.
Safety
Features :
Exhaust system : 2” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 1200Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
25 NAPKINS PER CYCLE |
---|---|
MODE |
FULL AUTOMATIC |
FULL AUTOMATIC |
250B x 520H x 250L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front-loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating Element : Kandhal type heating element embedded in ceramic.
Power Cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Air tight front loading inlet door
Loading capacity : 150 napkins per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less in such cases there is a probability of complaints due to over heating or over loading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
25 NAPKINS PER CYCLE |
---|---|
MODE |
FULL AUTOMATIC |
FULL AUTOMATIC |
250B x 520H x 250L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front-loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating Element : Kandhal type heating element embedded in ceramic.
Power Cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Air tight front loading inlet door
Loading capacity : 150 napkins per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less in such cases there is a probability of complaints due to over heating or over loading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
25 NAPKINS PER CYCLE |
---|---|
MODE |
FULL AUTOMATIC |
FULL AUTOMATIC |
250B x 520H x 250L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front-loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating Element : Kandhal type heating element embedded in ceramic.
Power Cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Air tight front loading inlet door
Loading capacity : 150 napkins per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less in such cases there is a probability of complaints due to over heating or over loading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
25 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC WITH BLOWER |
AUTOMATIC WITH BLOWER |
600Hx250Bx250L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
10 - 12 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin , 16 amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 200 Napkins per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 2” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Air blower : Advanced air filtration system to reduce smoke
Bottom Burning
Chamber :
USAGE |
200 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC WITH BLOWER |
AUTOMATIC WITH BLOWER |
400H X 400B X 750L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
2000w |
BURNING TIME |
15MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin , 16 amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 200 napkins per time - 6cycles per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Air blower : Advanced air filtration system to reduce smoke
Bottom Burning
Chamber :
USAGE |
10 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC |
DIAMENTIONS |
220Lx220Bx390H |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
1200w |
BURNING TIME |
10 - 12 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 1.5 Sq mm 3core cord, 1.5m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin , 6 amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 50 napkins per time - 10cycles per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 2” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Air blower : Advanced air filtration system to reduce smoke
Bottom Burning
Chamber :
USAGE |
400 NAPKINS PER CYCLE |
---|---|
MODE |
FULLY AUTOMATIC |
DIAMENTIONS |
600LX460BX800H |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
3 INCH FLEXIBLE HOSE |
HEATER |
3000W |
BURNING TIME |
30 MINUTES |
Case Work : Constructed with epoxy coated thick sheet metal
Heater Base : Made of Mild Steel
Loading Door : Freely operating hinged top loading door, ceramic insulated airtight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 400\cycle - 6 cycle per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 3000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
10 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC |
DIAMENTIONS |
600LX460BX800H |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
1200 watts |
BURNING TIME |
10-12 MINUTES |
Case Work : Constructed with epoxy coated thick sheet metal
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged top loading door, ceramic insulated airtight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 1.5 Sq mm 3core cord, 1.5m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 50 per day - 10napkins at a time
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 2” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 1200Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
100 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC |
DIAMENTIONS |
1250Lx360Bx360H |
OPERATIONS |
TIMER CUTT OFF AND TEMPERATURE CUT OFF |
EXHAUST |
3’ INCH FLEXIBLE HOSE |
HEATER |
4000W |
BURNING TIME |
30 MINUTES |
Case Work : Constructed with epoxy coated thick sheet metal
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged top loading door, ceramic insulated airtight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Power cord : 2.5 Sq mm 3core cord, 1.5m length
Working Temperature : Operating temperature range: 350C-950C Controlled by temperature controller
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Removable Ash tray for easy disposal of ash
Plug : 3 Pin, 16-amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 600 Napkin per day - 100 Napkins per time
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 4000w for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
600 NAPKINS PER CYCLE |
---|---|
MODE |
FULLY AUTO MATIC |
DIAMENTIONS |
1010H X 460B X 600L |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
3 INCH FLEXIBLE HOSE |
HEATER |
3000W |
BURNING TIME |
30 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged top loading door, ceramic insulated airtight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 2.5 Sq mm 3core cord, 2m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin, 16 amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 600 Napkins per cycle - 6 cycle per day (4000 Napkins per day)
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to pre-set timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 3” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 3000Kw for quick combustion and longer life.
Bottom Burning
Chamber :
USAGE |
10 NAPKINS PER CYCLE |
---|---|
MODE |
AUTOMATIC |
DIAMENTIONS |
220Lx220Bx390H |
OPERATIONS |
TIMER CUTT OFF |
EXHAUST |
2 INCH FLEXIBLE HOSE |
HEATER |
1200w |
BURNING TIME |
10 - 12 MINUTES |
Case Work : Constructed with epoxy coated Mild Steel (MS)
Heater Base : Made of Stainless Steel SS304
Loading Door : Freely operating hinged Front loading door, ceramic insulated air tight metal door, prevent heat loss
Air Control : Vent provided in the bottom and top of the unit for free air circulation and quick combustion.
Heating element : Kandhal type heating element embedded in ceramic.
Power cord : 1.5 Sq mm 3core cord, 1.5m length
Working Temperature : Operating temperature range: 350C/500C
Switch : Heavy duty switch
Insulation : Ceramic insulation for external thermal protection.
Ash Collection : Insulated Ash tray for easy disposal
Plug : 3 Pin , 6 amp heavy duty anchor plug
Power Requirement : 220/240V
Process : Automated and electrically operated
Inlet Door : Fully insulated Airtight front loading inlet door
Loading capacity : 50 napkins per time - 10cycles per day
Interval Timer : To control the running time, it is programmable according to the usage volume, this function helps the machine to cut off after a particular time after the completion of the burning process. Reduces power consumption and provides a longer life in the case of analogue timer we can’t adjust the time as per our wish, it could be adjusted only to preset timings so either the electricity consumption will be very higher or very less. in such cases there is a probability of complaints due to over heating or overloading of machine.
Safety
Features :
Exhaust system : 2” emission outlet for easy combustion on the back side.
Electrical Specification : Power Plug socket with Proper Grounding Required to install
Heating Element : High efficiency ceramic embedded kandhal type heating element, 2000Kw for quick combustion and longer life.
Air blower : Advanced air filtration system to reduce smoke
Bottom Burning
Chamber :
